The 2027 Orbea Orca M30i in Diamond C.View/Titan Grey pairs an OMR carbon frameset with Shimano 105 Di2 12-speed, an adjustable OC cockpit, tubeless-ready alloy wheels, Continental Grand Prix 28mm tyres and a carbon seatpost.
The 2027 Orbea Orca M30i in Diamond C.View/Titan Grey pairs an OMR carbon frameset with Shimano 105 Di2 12-speed, an adjustable OC cockpit, tubeless-ready alloy wheels, Continental Grand Prix 28mm tyres and a carbon seatpost.
ORBEA

2027 Orbea ORCA M30i Road Bike - Diamond C.View Matt/Titan Grey Gloss

£3,199.00
Earn
in Customer Rewards when you buy this item today
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined
Earn Rewards
When you purchase this item, you will earn of rewards points to spend on your next purchase from us. You can spend your Rewards balance in-store & online.

28 day returns

Refunds and Returns Policy

We guarantee to replace or refund faulty products covered by manufacturers warranty subject to inspection of goods and manufacturers approval.

We will replace or refund goods which don't fit or are unsuitable provided the goods are returned unused and in the original packaging within 28 days of delivery.

The quickest option is to drop the stock back to us in store along with a copy receipt but alternatively we have made the online returns process as simple as possible for you.

1)            Give us a call on 01952 763274 or email us to say you're sending something back

2)            Pop a note in, together with a copy receipt, with the item to say whether you'd like a refund or an exchange for a different product

3)            Post it back to us at Plush Hill Cycles, Unit 9A, Birchfield Way, Lawley, Telford, TF3 5BZ and make sure you get a proof of postage

4)            The item is your responsibility until it reaches us. For your own protection, we recommend that you send the parcel using a delivery service that insures you for the value of the goods.

5)            The cost of returning the item to us is your responsibility.

6)            The parcel can take up to 7 working days to be processed once received.

Promotional items: When returning items that were purchased online as part of a ‘Buy One, Get One Free’ offer, 'Buy One, Get One Half Price' offer, '3 for 2' offer, or a 'Buy , Get a Free' offer, all of the items involved in the offer must be returned.

When returning goods, if no fault is found we do not refund delivery charges and may charge for collecting the goods if they are not brought into our store.

All Custom Builds and 'Made to Order' items require a 20% deposit on order, with the balance payable at pick-up/delivery and are, unless faulty, non-refundable.

Deposits on Special Order Items are non-refundable.

Items ordered specially into store will be held in-store for 14 days from the time that customers are notified that they are available for pick-up (unless otherwise agreed). If goods are not collected in that time they will added to shop stock and made available for general sale, deposits are non-refundable.

2027 Orbea ORCA M30i Road Bike - Diamond C.View Matt/Titan Grey Gloss

Season:2027

Brand:ORBEA

Code:U107TTCCA6

The 2027 Orbea Orca M30i in Diamond C.View Matt / Titan Grey Gloss is a straightforward, performance-focused carbon road bike that brings Shimano 105 Di2 electronic shifting to Orbea’s light and responsive OMR platform.

The OMR carbon frame and full-carbon ICR fork share the same modern Orca design language as the higher-tier models, including internal cable routing and clearance for contemporary road tyres. Shimano 105 Di2 provides 12-speed shifting, while the separate OC RP31 handlebar and RP23 stem make fit adjustments simple and the tubeless-ready alloy wheels keep the specification practical.

Our opinion: This is the sensible route into an electronic-shift Orca. The alloy wheels leave clear upgrade potential later, but the frame, carbon seatpost and 105 Di2 group are all strong foundations. It is a bike we would be happy to sell as-is and equally happy to help develop over time.

Key Features & Performance Highlights

  • OMR Carbon Frame and Fork: Lightweight monocoque frame with full-carbon ICR fork and clean internal routing.

  • Shimano 105 Di2: 12-speed electronic drivetrain with compact 34/50T gearing and an 11–34T cassette.

  • Adjustable OC Cockpit: Separate RP31 handlebar and RP23 stem make fine-tuning fit more straightforward.

  • Tubeless-Ready Alloy Wheels: 700c alloy wheelset fitted with Continental Grand Prix 700x28c tyres.

  • Useful Everyday Details: Fizik Aliante R5 saddle, carbon seatpost and integrated OC Toolbox storage.
Technical Information

Fork

Orbea Orca OMR ICR 2024, full carbon, 1-1/8" - 1,5" tappered head tube compatible, Thru axle 12x100mm, thread M12x2 P1.

Frame

Orbea Orca carbon OMR 2026, monocoque construction, HS 1,5", BB 386mm, powermeter compatible, Rear Thru Axle 12x142mm, thread M12x2 P1, internal cable routing.

Headset

FSA 1-1/2" Integrated Aluminium Cup

Crankset

Shimano 105 R7100 34x50t

Shifters

Shimano Di2 R7170

Cassette

Shimano 105 R7100 11-34t 12-Speed

Rear derailleur

Shimano 105 Di2 R7150

Front derailleur

Shimano 105 Di2 R7150

Chain

Shimano M6100

Handlebar

OC Road Performance RP31, Reach 80, Drop 125

Stem

OC Road Performance RP23, -5º

Brakes

Shimano R7170 Hydraulic Disc

Brakes Configuration

N/A

Wheels

Alloy, Tubeless, 700c, 19c, 28H

Tyres

Continental Grand Prix Foldable 700x28c

Front Wheel Axle

Orbea Thru Axle 12x100mm M12x2 P1 Hollow

Rear Wheel Axle

Orbea Thru Axle 12x142mm M12x2 P1 Hollow

Saddle

Fizik Aliante R5

Seatpost

SP 0.2 Carbon, 27.2mm, Setback 20

Handlebar Tape

OC Components

Storage

OC Toolbox TB02PP
