Fork
Marzocchi Bomber Z2, 140mm travel, Rail damper, remote Push-Lock, QR15x110mm
Frame
Orbea Occam Hydro aluminium, Concentric Boost 12x148mm rear axle, Pure Trail geometry, internal and external cable-routing compatibility, asymmetric design, 29" wheels and linkage compatibility with the OC multitool
Rear Shock
Fox Float Performance Remote Push-Lock, EVOL, custom tune, 210x50mm
Remote Lockout
OC Squidlock MP11, suspension and dropper-post control
Headset
FSA 1-1/2" Integrated Aluminium Cup
Cable Routing
Internal cable routing
Crankset
Forged alloy, 32T
Shifters
Shimano Deore M6200 I-Spec EV
Cassette
Shimano CS-M6200, 10-51T, 12-speed
Rear Derailleur
Shimano Deore M6200 SGS Shadow Plus
Chain
Shimano M6100
Handlebar
OC Mountain Control MC30, 20mm rise, 800mm width
Stem
OC Mountain Control MC21, 0°
Computer Mount
N/A
Brakes
Shimano MT201 hydraulic disc brakes
Brakes Configuration
N/A
Wheels
Alloy, tubeless compatible, 29", 29mm internal width, 32H
Front Tyre
Maxxis Dissector 2.40", 60 TPI, rigid, EXO, tubeless ready
Rear Tyre
Maxxis Rekon 2.40", 60 TPI, rigid, EXO, tubeless ready
Saddle
Selle Royal 2058 DRN
Seatpost
OC Mountain Control MC22, 31.6mm dropper post
Grips
OC Lock On
Storage
Orbea LOCKR accessory containers
Tools
N/A
